50KPA All Types Of Pneumatic Boat Side Rubber Fender Yokahama Fender Marine Quay Dock Fender
Pneumatic rubber fender is the advanced anti-collision device for marine application in the world today. It uses compressed air as medium to absorb the impact energy in a collision between ship and ship or ship and dock,etc. So that it can prevent ship and dock from damages.
Advantages of FL marine rubber fender:
* Good quality have been checked by many buyers
* Optional tire and chain,can provide chain with hot galvanizing or stainless steel(304,312,316)
* High quality narural rubber imported from Thailand
* High technical study team
* A serious of advanced product equipment
* Clear devision of labor
* High quality stuff and sincere service attitude
Applications of FL marine rubber fender:
* Tankers, Gas Carries and Bulk Cargo Ships;
* Fast ferries and aluminum hulled vessels;
* Temporary of permanent installations;
* Rapid response and emergency fendering;
* As stand-off fenders to realign ships with shore facilities.
Technical performance of marine rubber fender
| Specification DXL(m) | 0.05Mpa(Initial pressure 0.05Mpa) | (Initial pressure 0.08Mpa) |
| Weight(kg) | Reaction force(KN) | GEA (KJ) | Weight (kg) | Reaction force(KN) | GEA (KJ) |
| 1.2X2.0 | 120 | 297 | 63 | 165 | 390 | 88 |
| 1.35X2.5 | 165 | 427 | 102 | 226 | 561 | 142 |
| 1.5X3.0 | 315 | 579 | 153 | 370 | 761 | 214 |
| 1.7X3.0 | 405 | 639 | 191 | 436 | 840 | 287 |
| 2.0X3.5 | 590 | 875 | 308 | 632 | 1150 | 430 |
| 2.5X4.0 | 1050 | 1381 | 663 | 1110 | 1815 | 925 |
| 2.5X5.5 | 1333 | 2019 | 943 | 1410 | 2653 | 1317 |
| 3.0X5.0 | 1880 | 2000 | 1050 | 2155 | 2709 | 1571 |
| 3.0X6.0 | 2160 | 2488 | 1312 | 2470 | 3292 | 1888 |
| 3.3X4.5 | 2020 | 1884 | 1175 | 2300 | 2476 | 1640 |
| 3.3X6.0 | 2300 | 2783 | 1675 | 2600 | 3652 | 2338 |
| 3.3X6.5 | 2700 | 3015 | 1814 | 3080 | 3961 | 2532 |
| 3.3X10.6 | 4403 | 5257 | 3067 | 5020 | 6907 | 4281 |
| 4.5X9.0 | 6554 | 5747 | 4752 | 7470 | 7551 | 6633 |
| 4.5X12 | 8739 | 7984 | 6473 | 9960 | 10490 | 9037 |
| Note:The weight is the fender body weight(without tires and chain),with weight error of ±10% and counterforce error of ±10% |
Notes about FL rubber fender
* Frequently check whether the fender body si damaged and whether the pressure is normal,and the valve core must be replaced every six moths
* The steel wire should wrap the rubber pipe,when trying steel wire to pneumatic rubber fender in case the fender is stabbed
* The surface or subject next to the pneumatic rubber fender can’t be hard and sharp-pointed in case the pneumatic rubber fender is stabbed
* The accessories and jip’s nuts can’t be loose when testing the internal pressure
* The rope net should be reliable,the steel wire used for hanging metal parts and the hook link can’t be tied in disorder.
Storage of FL rubber fender
* When not using for a long time,wash the surface of the fender,dry up and fill in sufficient right amount of compressed air to lay them in a cool.dry and well-ventilated place.
* The storage place of pneumatic rubber fender should be far away from hear source
* Try to keep fender away from acid,alkali,grease and organic solvents
* When not applying the fenders,the pneumatic rubber fender can’t be piled up and heavy items can’t be piled on the fender
Package of FL rubber fender
1. Nude packing
2. Packed in weaving bag
3. Packed in wooden case
4. Packed in 20'GP 40'GP 40HQ or open top containers
5. As clients' requirement
